Engineering Update: 2024 GM Light Configurations

Posted on by Mary Faulds

Models Affected:  All 8’ ChallengerST Service Bodies mounted on 2024 GM Trucks

In order to continue providing exceptional support to our valued distribution partners, we want to share a recent communication from General Motors that will have a significant impact on your installation process. Below you will find GM Bulletin (194). It has come to our attention that the 2024 GM trucks now feature multiple taillight configurations, depending on the trim level of the truck. While some of these light configurations have a separate wire for stop lights, the majority of models have combined wires for stop and turn signals. As a result, this GM change necessitates a modification in our approach to adaptor plugs on GM trucks. The esteemed STAHL Engineering team has devised the following approach:
  • For every GM box removal truck, it is imperative to utilize adaptor plug 244046.
  • For GM lighting arrangements that have a separate circuit for stop lights, an additional adaptor plug with part number 245091 will be required. There are two ways to determine which trucks will necessitate the second adaptor:
    1. Review the attached GM bulletin, which outlines both the trim levels with the extra circuit and how to identify them based on the taillight housings.
    2. During the testing of lights after body installation, if the stop lights are not functioning, please install the add-on adaptor.
Please note that these two steps pertain only to box removal applications. Factory box deletes and cab chassis’ will require a different adaptor approach. We anticipate that the add-on adaptor will only be necessary for higher trim levels. We estimate that it will be required for approximately 15% to 20% of GM applications with an installed STAHL service body. For more detailed information, please refer to the attached communication from General Motors.

Should you have any inquiries regarding this bulletin, please do not hesitate to contact Jake Stickney at (330) 202-4241.



Additional Information Link from GM

Engineering Bulletin: New Serial Tag Format

Posted on by Mary Faulds

Engineering Bulletin: New Serial Tag Format

At STAHL, we are constantly seeking ways to deliver not only top-tier service bodies but also exceptional customer experiences. We are excited to share with you a significant enhancement – our new and improved serial tags for service bodies, designed with your convenience in mind. One of the driving forces behind this upgrade was the recognition that paper copies of warranties can be easily misplaced, and navigating websites for parts and warranty information can be a time-consuming hassle. Our mission is to save you time and reduce any unnecessary stress, and this idea was inspired by one of our own employees who truly understands the value of efficiency. Constructed from sturdy metal, these upgraded serial tags are built to match the durability of our truck bodies, ensuring they will withstand the harshest conditions and remain legible throughout the lifespan of your vehicle.

New Tags Better for You!

The addition of a QR code on the tag marks a new era of efficiency. Your serial number is vital when ordering replacement parts or filing warranty requests. With our revamped serial tags, we aim to simplify this process for you. With a quick scan, you’ll have direct access to warranty information, making the process of filing the rare warranty claim a breeze. But that’s not all; we have even more exciting plans in store for the future! In the pipeline, we are developing a portal that grants you direct access to our parts department, all through the convenience of scanning the code.

No Change in Tag Placement

Rest assured, the serial tag locations for STAHL service bodies, Arbortech Chip Bodies, and standalone L-boxes or Underbody Boxes will remain consistent, ensuring familiarity and ease of identification. For STAHL service bodies, the serial tag will be located inside the front streetside compartment on the back compartment wall. Meanwhile, for Arbortech Chip Bodies, you can find the serial tag conveniently on the front curbside face of the Chip Body. Finally, for standalone L-boxes or Underbody Boxes, your serial tag will be placed on the inside of the front panel of the curbside box. At STAHL, our customers are at the core of everything we do, and these upgraded serial tags exemplify our dedication to providing unmatched service and support. Together, we’re forging a smoother and more streamlined future for all our valued customers. Stay tuned for more updates, and thank you for being a valued part of the STAHL Truck Bodies family!

New Serial Tag Design

Sample STAHL Body Placement

Sample Arbortech Body/L-Box Tag Placement

Questions? Drop us a line!

Need a new truck body? Find your local STAHL distributor!

Looking for parts? Search our Amazon store!

Looking for info about Arbortech? Click here.

Engineering Bulletin: Wiring for 2023 Ford Box Removals

Posted on by Mary Faulds

For All STAHL Distributors

Models Affected: All STAHL Service Bodies

STAHL Engineering continues to adapt to the OEM model year changes in order to keep the installation of our service bodies easier and faster than the competition. Due to the wiring change Ford has implemented for 2023 box removal wiring, STAHL has created a new adaptor plug that will be STAHL part #244043. These new adaptors are expected to be available in late August 2023.

Until such time that the 2023 Ford Adaptor Plugs are available, STAHL Engineering is recommending following the process documented in the drawing below.

Please contact the Engineering Department at (330) 202-4241 with any questions regarding this bulletin.

Engineering Bulletin: Service Body Lighting Upgrade

Posted on by Mary Faulds

To all STAHL Distributors

Models Affected: All STAHL Service Bodies

As STAHL Engineering continues to find ways to make the installation of our service bodies easier and faster for our customers, we are excited to share that an update to STAHL’s service body lighting will be releases on June 1, 2023. The changes will include:
  1. Updated license plate lighting. We are updating our license plate lighting from (1) incandescent light to (2) LED lights. The snap-in light design will improve visibility and cut installation time.
  2. Provisions to mount stop/tail/turn lights in either the body or the bumper. We will start pre-punching both the body and the bumper to allow the installation of the stop/tail/turn light assemblies in either location. This will save installers the time currently required to cut out and touch up holes when body mounted lights are desired.
  3. The ability to cover up unused lighting holes. STAHL will now provide a molded reflective carrier to be installed into whichever pre-punched hole (body or bumper) that is not utilized by the stop/tail/turn light assembly. These two reflector placements are confirmed to meet federal requirements and are recommended by STAHL. Please see the pictures and notes below.
These changes will be included on every service body shipped after June 1, 2023. While every effort will be made to prevent it, there could be a short period of time during this transition where bodies are mixed.

Please contact our Engineering Department at (330) 202-4241 with any questions regarding this bulletin.
